The MOTU M6 is a high-performance audio interface, perfect for professionals who demand exceptional sound quality. Powered by ESS Sabre32 Ultra™ DAC technology, it delivers an impressive 120 dB dynamic range and ultra-clean preamps with -129 dBu EIN performance, ensuring pristine audio capture and monitoring. Whether recording dialogue, sound effects, or Foley, the M6 will assure a seamless workflow.
Engineered for best-in-class speed, the M6 provides ultra-low 2.5 ms round-trip latency at 96 kHz, making it ideal for real-time monitoring of live inputs like microphones, guitars, and keyboards. The full-color LCD with detailed level metering helps you maintain perfect volume control while recording or mixing, enhancing precision for any project.
Featuring advanced capabilities like loopback channels for streaming, A/B monitor switching, and stand-alone operation with an optional DC power adapter, the M6 is an invaluable tool for sound engineers. It combines rugged build quality with versatile connectivity, making it the ideal choice for professional audio work.
MOTU M6 features
- ESS Sabre32 Ultra™ DAC Technology
- 120 dB Dynamic Range on Outputs
- -129 dBu EIN on Mic Inputs
- 2.5 ms Round Trip Latency
- Full-Color LCD with Detailed Level Meters
- Loopback Channels for Live Streaming
- A/B Monitor Switching
- Stand-Alone Operation with Optional DC Power Adapter
MOTU M6 Specifications
| Sample rates |
44.1, 48, 88.2, 96, 176.4, 192 kHz |
| Mic/line/guitar |
4 x XLR/TRS "combo jack" mic/line/Hi-Z guitar inputs
Independent preamp gain, 48V phantom power and monitor switch for each input |
| Analog inputs |
2 x 1/4" line in |
| Analog outputs |
4 x 1/4" TRS line out (balanced, DC coupled)
2 x 1/4" TRS stereo headphone with independent volume |
| Computer I/O |
1 x USB-C 2.0 audio class compliant
Compatible with USB Type A host (*see power below)
USB C-to-C and C-to-A cables included |
| MIDI I/O |
1 x MIDI IN
1 x MIDI OUT
16 MIDI channels to/from computer host |
| Headphones |
2 x 1/4" TRS stereo headphone with independent volume
1 x 3-4 switch for optional monitoring of Line Out 3-4 |
| Phantom power |
4 x individual +48V |
| Front panel |
2 x 1/4" TRS headphone output
1 x potentiometer • monitor vol
2 x potentiometer • phone vol
1 x potentiometer • input monitor mix
4 x potentiometer • mic/line/guitar input gain
11 x switches • (4) 48V, (5) MON, (1) A/B and (1) 3-4
160 x 128 pixel full-colored LCD with input and output level meters |
| Power |
Bus-powered through USB*
Optional multi-blade international 15V DC power adapter (included), 1.0A max • tip pos or neg, supports 100-240V power sources (US/Japan, EU, UK, Australia)
|
| Dimensions and weight |
(width x depth x height, enclosure only)
9.21 x 4.75 x 1.8 inches
23.4 x 12.0 x 4.57 cm
2.15 lbs / 0.975 kg
|
