The Neumann KH 80 DSP AG 2-way, active near-field Monitor is an ultra-compact near-field monitor with exceptional power reserves. With its digital core, the KH 80 DSP enables filtering functions and room adjustment options, which brings reference level reproduction to any environment.
Even with its compact design, it has extraordinary reserve capacity as well as the classic strengths of the Neumann monitor philosophy, that is clearly defined dispersion angle, distortion-free design and sophisticated material selection.
Neumann KH 80 features
- DSP engine optimizes output to achieve reference class sound
- Ready for fully-automatic room alignment and precise adjustment using the Neumann control-app
- Mathematically optimized dispersion to deliver excellent detail in any surroundings
- Powerfull alloy fabric dome
- Elliptical mathematically modelled dispersion waveguide
- Two colour and dimmable Neumann logo displays operation status
- Long-throw composite sandwich cone bass driver for damping
- Robust metal grill
- Large front panel ports reduce bass compression
- Wide horizontal but narrow vertical dispersion
- Powerful highly efficient amplifiers with large headroom
- Separate limiters for woofer and tweeter
- Available in anthracite and white
Neumann KH 80 Specifications
| Frequency Response (+/-6 dB) |
53 Hz – 21 kHz |
| Frequency Response (+/-3 dB) |
57 Hz – 21 kHz |
| Linearity Deviation (100 Hz – 10 kHz) |
+/- 0.7 dB |
| Self-Generated Noise (10 cm) |
<20 dB(A) SPL |
| Max SPL (1m, 3% THD, 100 Hz – 6 kHz) |
108.8 dB SPL (half space) |
| Max SPL (Full Space, 1m, 3% THD) |
102.8 dB SPL |
| Analog Inputs |
XLR, 6.3 mm Jack (electronically balanced) |
| Max Input Level |
+24 dBu for 94 dB SPL setting |
| Digital Converter Sampling Rate |
48 kHz |
| Dynamic Range (A-D) |
114 dB(A) |
| Latency |
2 ms (A-D-A Linear Phase) |
| Crossover Frequency |
1.8 kHz |
| Crossover Slope |
48 dB/oct (8th order) with phase correction |
| Woofer Power Output |
120 W (THD+N < 10%) |
| Tweeter Power Output |
70 W (THD+N < 10%) |
| Power Consumption (Full Output) |
180 W |
| Cabinet Material |
Composite polycarbonate |
| Product Dimensions (H x W x D) |
233 x 154 x 194 mm |
| Product Weight |
3.5 kg |
